Insulated FRP Dog Bone and Corner Angle
I-beam spacer, also known as I-beam, drawbar, ventilator bar, etc., is a high-performance profile made of alkali-free glass fiber impregnated with thermosetting resin and produced by pultrusion process. Used for transformers, reactors, etc
Categories：
Glass fiber products
WhatsApp：+8615290922111
Email：info@hnzfe.com
Product Description：
Bars - dogbone (dog bones) are very strong, flame-resistant and have excellent dielectric properties. Specific features: large physical strength, dimensional stability, dissolving resistance, fire resistance, low water absorption. Dogbone bars are made of the same material as Glastic SG - 200 boards with a temperature index of 210 °C.
Insulated FRP Dog bone and Corner Angle for transformer
1,Fiberglass FRP dogbone is made by non-alkali fiberglass epoxy resin after high temperature curing lead continuous forming . H shape and I shape are used as for transformer insulation parts.
2,Raw Materials :
Fiberglass, Epoxy or Polyester Resin, vinylester ,Curing agent.
3,Temperature Class :
F & H.
4,Size: 8x10mm, 6x6mm, 4×8mm,18×20mm, 10×16mm, 16×16mm etc.
5, Application: Mainly use in a variety of electrical products, like transformers, electric reactor and motor wedgs. Insulation
pultrusion profiles are widely used in railway ,subway ,tramway ,Power electrical insulation ,cable tray channel,ladders,reinforce
core for cable; drain channel, water transporting system ,tooling handles,sport apparatus, garden facilities ,etc
Advantages:
• High mechanical strength
• Very good electrical isolation
• Low weight
• Easy installation
• High safety against brittle fracture
• High safety against vandalism
Product quality standards：
Application:
it is suitable for high insulation structure parts of machinery, electric appliance and electron, with high heat and moisture resistance.high-voltage transformer fittings, electrical and electronic insulation parts, water conservancy and hydropower insulation parts, switch cabinet insulation parts, frequency converter insulation parts, industrial furnace insulation parts,Semiconductor insulation parts, electrified railway insulation parts, ship manufacturing insulation parts, nuclear power insulation parts, bus groove insulation spacer. It is one of the widely used insulating materials at present.
Product Technical Parameters：
| Indicator name | unit | index | |
| density | g/cm2 | 1.8-2.0 | |
| Water absorption rate | % | ≤0.5 | |
| Barcol hardness | – | ≥50 | |
| Tensile strength (parallel fiber direction) | MPa | ≥100 | |
| Tensile modulus (parallel fiber direction) | MPa | ≥1.0*104 | |
| Bending strength (vertical fiber direction) | 23 ± 2 ℃ | MPa | ≥150 |
| 130 ℃ | MPa | ≥70 | |
| Flexural modulus (vertical fiber direction) | MPa | ≥0.6*104 | |
| Compressive strength | Parallel fiber direction | MPa | ≥250 |
| Vertical fiber direction | ≥150 | ||
| Shear strength | MPa | ≥70 | |
| Insulation resistance | Ω | ≥1.0*1012 | |
| Surface resistivity | Ω | ≥1.0*1011 | |
| Breakdown voltage in the fiber direction (in air) | KV | ≥45 | |
| Arc resistance | s | ≥182 | |
| Flammability | – | FV0 | |
